Overview
Direct Drive Fluid Coolers for use with water or glycol/water mixtures as fluids for:
- Process Fluid Cooling
- Glycol and “Free Cooling” for Computer Room (Data Center) Cooling
- Secondary Heat Exchangers
- Secondary Fluid for Supermarket Systems
- Remote Radiators for Diesel or Gas Engines
Features/Options
Features:
- Narrow width design to suit shipment in containers.
- Standard 850 RPM quiet low speed dual voltage (230/460) fan motors with male electrical plug, moisture slinger, and rainshield for complete weather protection.
- Swept wing fan for quiet operation and optimal efficiency
- Rugged heavy-gauge galvanized steel rail
- All fan sections individually baffled with full height partitions, and clean-out panels.
- Complete selection of electrical fan cycling and speed control options.
- Heavy-gauge galvanized steel cabinet construction assembled with zinc plated huck bolts supported on heavy-duty legs.
- 24” legs
- Terminal block
- Single entering electrical service
- Control circuit voltage – 230 V
- Control circuit transformer where applicable
Available Options:
Optional features (Factory Mounted)
- Fan Cycling – Ambient thermostat / fan row with contactors
- Fan Cycling – Aquastat thermostat fan cycling control /outlet fluid temperature
- Individual fan motor fusing
- Non-fused disconnect
- Horizontal air discharge configuration
- Variable Speed EC Motor which provides optimum efficiency and sound levels
- Extended leg kits (36” or 48”) with cross bracing for extra rigidity
- Optional 550 ultra low and 1140 RPM high speed motors
- Mounted flange sets (factory installed)
- Optional fin materials
- Optional coil coating
- Voltages available for 60Hz or 50Hz
Specifications
Application:
- Water or glycol/water mixtures as fluids
- Process Fluid Cooling
- Glycol and “Free Cooling” for Computer Room (Data Center) Cooling
- Secondary Heat Exchangers
- Secondary Fluid for Supermarket Systems
- Remote Radiators for Diesel or Gas Engines
- Suitable for other process cooling applications beyond water & water/glycol mixtures (i.e.: Solest POE Oil, Transformer Oil, Hycool 20, etc.)
Capacity:
- ONE TO FOURTEEN FAN MOTORS
Electrical:
- 208-230/3/60
- 460/3/60
- 575/3/60
